The compact yarding system
KR40-2
The KR40-2 is a self propelled, remote controlled skyline crane. The essential difference to the KM40-2 : the hydrostatic chaindrive system!
The compact yarding system
The KR40-2 is a remote controlled skyline crane which is mounted on a tandem trailer. The operation of the installation is remote controlled. To increase the productivity, an automatic drive function of the carriage is standard. Very comfortable is the rigging up of this installation.
All the functions can be operated by remote control. This installation connects a high grade of working safety with an outstanding productivity.
In terms of tractive force, performance data and variety of options, the KR40-2 is identical to its brother, the KM40-2.
Radio technology
For a quick installation and a safe handling, the following functions are controlled by remote:
- Supports
- Putting up the tower
- Radio technology
- Guyline drums
- Skyline winch
- Ram cylinder for tension part of drum
- Guyline winch
- Mainline winch
- Carriage start/stop
- Winch in carriage
- Automatic drive function
- Function transfer radio control
- Horn
KR 40-2
Measurements
KR 40-2
Technical data
General Information
| Weight | ca. 17000 kg ¹) |
|---|---|
| Transportmaße (L x W x H) | 4,98 x 2,20 x 2,96 m |
| Tower height | 10,8 m ¹) ²) |
| Control system | KTC 1.0 |
| Remote System | KFS-16, KFS-20 |
| Axiliary drive | chain drive unit, radio controlled |
| Driving speed | 0 - 4 km / h |
Cable crane system
| Pulling force | Cables | ||
| Standard | Long rope | ||
| Sky line winch | 120 kN | Ø20mm / 600m | Ø22mm / 800m |
| Main line winch | 40 kN | Ø12mm / 600m | Ø12mm / 800m |
| Guy line winch | 9 kN | Ø18mm / 60m | Ø18mm / 70m |
| Straw line winch ³) | 18 kN | Ø7mm / 1200m | Ø7mm / 1600m |
| Haul back line winch ³) | 40 kN | Ø11mm / 1200m | Ø11mm / 1600m |
Engine
| Stage III A (Tier 3) | Stage III B (Tier 4i) | Stage V | |
|---|---|---|---|
| Motor type | watercooled FPT 6-cylinder turbo diesel engine | ||
| Power (2200 U/min) | 175 kW | 210 kW | 212 kW |
| Torque (1500 U/min) | 1020 Nm | 1143 Nm | 1160 Nm |
| Total displacement | 6,7 l | ||
| Diesel tank capacity | 170 l | ||
Hydraulic system
| Cable crane pumps | axial piston pump, closed oil circuit, pmax 460 bar |
|---|---|
| Power takeoff pump | axial piston pump, open oil circuit, pmax 280 bar |
| Filling cap. hydraulic oil tank | 160 l |
1) Depending on the respective machine version
2) Version: 3-rope, with sky line discharger
3) Optional
Optional equipment: In addition to the standard equipment, a broad range of optional equipment is also available. Further information on standard and optional equipment can be obtained from your KONRAD distributor.
The manufacturer reserves the right to make technical modifications and improvements.
